1kV(CAT II)
2kVpk(No Category)
■ Can be exchanged for springs, tips, etc.
Accessories example
(Accessories may change due to changes in specifications)
- Probe main unit
- Instruction manual
- Spring tip 0.8mm (probe tip)
- Solid tip 0.8mm (probe tip)
- Spring hook 5.0-L
- Insulator cap 5.0-L
- Protective cap 5.0-L
- Ground lead 22cm
Hard case type additional parts reference configuration
- BNC adapter 5.0-L
- Color ring 4 colors 3 pcs each
- Flexible adapter 5.0-L
- Ground lead 22cm-4mm banana plug
- Safety alligator clip
Specifications
| Model name | Attenuation | Input RC | Bandwidth [MHz] |
Compliant capacitance [pF] |
Cable length [m] |
Maximum input voltage [kV] |
||
|---|---|---|---|---|---|---|---|---|
| R[Ω] | C[pF] | CAT II rms |
No Category peak |
|||||
| PHV1000 PHV1000-RO PHV1000C PHV1000C-RO |
100:1 | 50M | 7.5 | 400 | 10~50 | 2 | 1 | 2 |
| PHV1000-3 PHV1000-3-RO PHV1000-3C PHV1000-3C-RO |
250 | 10~35 | 3 | |||||
| PHV1000-5 PHV1000-5-RO PHV1000-5C PHV1000-5C-RO |
9.5 | 120 | 10~50 | 5 | ||||
- “-RO” in the model name corresponds to ReadOut
- Models marked “C” include a hard case and optional accessories.
